Helical Pier Installation
Our rigs drive every helical pier to its engineered torque target, generally 10 to 30 feet deep, further where Haltom City's soil requires it.
Installation details- CALL US TODAY: (817) 402-7113
Engineered helical piers for Haltom City businesses, industrial sites, and new construction on Tarrant County's shifting clay. Family-owned since 2005, manufacturing, installing, and standing behind every pier ourselves.
Haltom City sits in the Mid-Cities, on the same shrink-swell clay that runs under most of Tarrant County. That clay expands when it absorbs water and contracts as it dries, so the ground under a slab shifts with the seasons instead of holding still, exactly the kind of movement a helical pier is built to anchor past.
Dry summers pull moisture from the soil beneath a slab; wet springs put it back. A helical pier is torqued into soil below where that seasonal swing reaches.
Much of Haltom City went up during the Mid-Cities building boom of the 1950s and 1960s, well before helical piers were a standard part of new construction. A helical pier retrofits under an existing shop, warehouse, or storefront without major demolition.
Roof drains discharging at the foundation, runoff from paved lots, and negative grade are common causes of cracks that look structural but often aren't. Fixing drainage first can reduce the pier count a design actually needs.
We measure an existing slab with a professional zip level before recommending anything. If the numbers point to drainage or age, we'll tell you that, not sell you a repair you don't need.
Each of these has innocent explanations on its own. Together, or spreading over time, they're a reason to measure.
One company handles the whole job: we manufacture the piers, install them with our own crews, and stand behind the result.
Our rigs drive every helical pier to its engineered torque target, generally 10 to 30 feet deep, further where Haltom City's soil requires it.
Installation details
The same J55 steel, ASTM A572 Grade 50 helical piers our crews install are sold direct, for engineers and contractors installing with their own teams.
Manufacturing & sales
Lift and stabilize a settling commercial slab with helical piers sized to the structure's load and Haltom City's clay profile.
See the processWe review the plans, the engineer's design, or the soil report, and approved projects get free test holes. On an existing building, a specialist measures elevations with a professional zip level and reviews its drainage history. If helical piers aren't warranted, we'll say so.
Where they are, pier count, spacing, and depth are engineered around your structure's load and Haltom City's soil.
Our own crews and rigs install to that design, tracking torque continuously so capacity is measured, not assumed.
Every pier's torque is logged against its location. Commercial work carries a 10-year warranty, and every job carries our Green Tag Guarantee.
Logos and badges are easy. These methods leave a record you can check on your own project.
Every pier advances to a torque target rather than a preset depth, since torque reflects that location's real soil capacity.
Each pier's achieved torque is logged against its exact location, the record an engineer or a future owner can check the installation against.
Compression tests measure downward capacity; tension tests measure resistance to uplift, both on hydraulic equipment that records movement under load.
When a structural engineer has produced the design, we build to it. Changes go back to that engineer first, never made in the field.
J55 carbon steelASTM A572 Grade 50ASTM A123 hot-dip galvanizingASTM A780 repair standard
Our crews train through our own Helical Trade School, and our CEO, Bill Vaughan, co-authored Next Day Helicals, the field manual other installers use for helical pier work.
| Criterion | Helical pier | Push pier | Drilled/poured pier |
|---|---|---|---|
| Carries load | Immediately on installation | Depends on structure weight for resistance | After concrete cures |
| Wet-weather clay | Installs in wet ground, no open excavation | Excavation needed; slower in wet clay | Holes can collapse in wet clay |
| Capacity verified by | Installation torque, logged per pier | Driving resistance | Design and inspection of the excavation |
| Depth reached | To torque criterion, not a set number | To refusal against structure weight | To designed depth |
"Big City Capability and Small Town Service! Bill Vaugn and team have the tools and expertise to solve any issues you may have, but the best part is the personal service and open and honest explanation of the entire process. Call FnD Piers, you will be in good hands."
"As business professionals, my husband and I have worked with FnD Piers for years. From its owner to its employees, they are one big family and their customers are part of the family. Over the top attitudes and altitudes. We highly recommend FnD Piers for its professionalism and integrity. The most trusted company in the business."
"FnD Piers is your go-to outfit for all things foundation! This Team is "the real deal.""
"FND Piers does excellent work — professional, efficient, and reliable every time. Their crew knows what they’re doing and gets the job done right. Highly recommend them for any helical pier or foundation work."
Haltom City sits immediately northeast of Fort Worth in Tarrant County's Mid-Cities. We install and sell helical piers across Haltom City's zip codes and the surrounding communities.
Just west, sharing the same Tarrant County clay.
Helical piers in Fort Worth →Bordering Haltom City directly to the east.
Helical piers in NRH →A short drive southeast along Loop 820.
Helical piers in Hurst →Northwest toward Eagle Mountain Lake.
Helical piers in Saginaw →Send plans, a soil report, or a description of the building, and we'll answer with a written quote. Approved projects get free test holes.
