Four ways to get a structure onto competent soil, compared on the things that decide a project: how capacity is verified, how fast the element carries load, what the weather does to your schedule, and what you are left holding as proof.
| Criterion | Helical pier | Drilled shaft | Driven pile | Pressed concrete piling |
|---|---|---|---|---|
| Carries load | Immediately on installation | After concrete cures | Immediately | Immediately |
| Capacity verified by | Installation torque, measured per pier | Design and inspection of the excavation | Driving resistance and dynamic testing | Hydraulic pressure at installation |
| Depth reached | To torque criterion, not a set depth | To designed depth | To refusal or designed depth | To refusal against structure weight |
| Works in wet weather | Yes, no open excavation or cure time | Poorly, holes collapse and cure stalls | Generally yes | Generally yes |
| Site disturbance | Low | High, spoil and excavation | Moderate to high | Moderate |
| Noise and vibration | Low | Low | High | Low |
| Access needed | Skid steer or mini-excavator | Drill rig, often large | Pile rig and crane | Compact, hand-portable in places |
| Resists uplift | Yes, tested in tension | Yes, by design | Limited | No |
| Documented per unit | Torque log per pier location | Inspection records | Driving records | Varies, often minimal |
| Where it wins outright | Verified capacity, immediate load, poor weather, tight access, uplift | Very high loads, large-diameter commercial work | Heavy marine and infrastructure, deep bearing at scale | Lowest cost on light structures |
Wins when: you need capacity you can verify rather than infer. The pier is rotated into competent soil and the installation torque correlates with capacity, so you get a per-location number as it goes in rather than a design assumption you hope holds. It takes load the day it is installed, so nothing waits on a cure. Rain does not stop it because there is no open hole. And it resists uplift as well as compression, which matters under wind and seismic loads and under anything that wants to lift.
Loses when: the loads are large enough that a large-diameter drilled shaft is simply the right structural answer, or the project is heavy marine or infrastructure work where driven piles are the established solution at that scale. It is also not the cheapest option on a small, light, straightforward job where a pressed piling would carry the load, and we will say so.
Wins when: loads are high and diameters need to be large. For heavier commercial structures a drilled shaft is often the straightforward engineering answer, and it is a very well understood element that every engineer and inspector in Texas is comfortable with.
Loses when: groundwater or unstable soil wants to collapse the hole, when the schedule cannot absorb cure time, or when the site cannot take the excavation and the spoil. It is also the method that suffers most in a wet season: an open excavation is a liability the moment it rains.
Wins when: the project is large infrastructure or marine work and you need deep bearing at scale. Driving resistance gives real feedback about what the pile is finding.
Loses when: the site has neighbors. Noise and vibration make it impractical in most occupied commercial and urban settings, and access requirements for a pile rig rule it out on constrained sites entirely.
Wins when: budget is the binding constraint on a smaller, light structure. It is the cheapest way to get segments under a slab, it is fast, and on a modest load in cooperative soil it can perform adequately.
Loses when: you want to know what you bought. Segments are pressed down using the weight of the structure itself as the reaction, so the depth reached is limited by how much building there is to push against, not by where competent soil actually is. That means the element may stop short of the bearing stratum, capacity is inferred from hydraulic pressure rather than verified, and there is often no per-location record. It also has essentially no uplift resistance. In expansive clay this is the method most likely to move again.
Every method above puts something in the ground. What separates them is whether you can prove what it is doing after it is buried.
A helical pier gives you a torque reading at each location, which correlates with the soil's capacity at the depth the pier stopped. That reading goes into a torque log with the pier location, so an engineer, an inspector or the next owner of the building can read what was achieved where. Where the engineer or the authority having jurisdiction wants more than that, piers can be load tested directly, in compression and in tension.
This is the argument for helical piers that survives contact with a sceptical engineer, and it is the one worth checking whoever you hire. Ask any contractor, including us, what document you are left holding when the backfill goes in. If the answer is a warranty certificate and nothing else, you have bought a promise rather than a verified installation.
No. On a light structure in cooperative soil, a correctly installed pressed piling can do the job for less money.
The case against it is not that it never works, it is that you cannot tell whether it worked. Where the load is significant, the clay is active, or you want a record of what was achieved, the verification difference is worth the cost difference. Where none of that applies, it may not be.
They work by going through it, transferring load past the active zone into soil that does not move with seasonal moisture.
The active zone is the problem in North Texas: clay swells when wet and shrinks when dry, and anything bearing on it moves with it. The design question is not whether the clay will move, it is whether your bearing stratum sits below the depth where it does.
Yes, and it is a primary use rather than a secondary one.
Commercial new builds large and small, deck and column supports, retaining structures, boardwalks and docks, equipment foundations, and midstream and energy infrastructure. On a new build the advantage is schedule: the foundation element is ready for load the day it goes in, so the trade behind you is not waiting on a cure.
Typically 10 to 30 feet in this region, sometimes 40 or more.
Depth is an output, not an input. The pier advances until it achieves the torque the design calls for, which is why installed depths vary across a single site and why a quote based on an assumed depth is a guess.
Then install a drilled shaft. The engineer of record's design governs.
Deviating from an engineered design without consulting the engineer is one of the more common and more serious mistakes in this trade. If you believe a helical pier is a better fit for the conditions, that is a conversation to have with the engineer before work starts, not a substitution to make in the field.
The soil decides more of this than the catalog does. Free test holes on approval mean the recommendation comes from your ground rather than from a preference.
